RetainWall Icon

RetainWall 2.60

Developed by - Windows, Other - setup file RetainWall_2.60_Trial.msi (3.48 MB) - Shareware
Buy or select mirror:

MD5: ac0cdc9a466f6a708a92d88bf4a848c0

All files are original. Download3K does not repack or modify downloads in any way. Check MD5 for confirmation.

Developer Description

"A retaining wall engineering design software."

Features:
- Load and resistance factors design (LRFD) capable
- Ready to use load and resistance factors combinations from AASHTO LRFD 2007, ACI 318-08 and IBC 2006
- Load and resistance factors editor to modify or create new combination
- Concrete reinforcement design from ACI 318-08
- Force diagrams (moment, shear and normal) for every combination
- Loads, resistances and reactions diagram for every combination
- Wall stabilities (bearing, sliding, overturning, rotation) for every combination
- Possibilities to choose active or at rest soil pressures
- Possibilities to choose elastic (rock) or plastic (soil) bearing pressures
- Possibilities to input user's soil pressure coefficients
- Reinforcement design for upper stem, lower stem, toe and heel
- Unit systems, properties, load and resistance factors, reinforcement design method, and page setup from last editing become the default for new design
- Possibilities to add other loads on wall
- Provide stability resistances from a shear key, toe passive soil pressure, adjacent structure, anchors or piles
- Enable or disable a shear key, water or seismic
- Support metric, SI and British unit systems
- Easy, clear, quick and simple software operation
- Help facilities, can be printed to create manual

RetainWall is a software mainly developed for the purpose of designing a concrete or masonry retaining wall. The wall may retain soil or other granular material. It analyses the stability of the wall based on the loads and resistances, and results in bearing pressure, sliding, overturning and rotational stabilities. Loads applied on the wall may consist of self weight, soil pressure, water pressure, live and seismic loads. Resistances may consist of base friction and cohesion, passive earth pressure, other structures or a shear key. Load and resistance factor design (LRFD) mode can be applied. If the wall is a reinforced concrete structure, the software also supports the reinforcement design.
